Silicone Rubber Cylinder screw from China manufacturer - Zhoushan Shenglong Machinery Co.,Ltd.

Product Detail

Means of Transport: Ocean,Land,Air

Packing: Wooden case

Brand Name: Shenglong

Steel Hardness after hardening&tempering: HB280-320

Nitrided case depth: 0.45-0.7MM

Design: Cool/hot feeding,silicon ru...

Alloy: bimetallic, nitriding, chor...

Production Capacity: 3000 units/month

Delivery Date: 30 days

Steel material: 38CrMoAla,SACM645,SKD61,GH1...

Nitriding hardness: HV900

Surface Roughness: Ra0.4

For what type plastic machiner: extruder machine

Raw material: silicon rubber

Screw structure, compression ratio and material can be changed according to different products and output.

Manufacturers of Silicone Rubber Cylinder/ Rubber Extruder Screw Barrel

Product Parameter:

Product	Rubber Extruder Screw Barrel
Hardness after hardening and tempering	HB260°~320°
Nitrided Hardness	HV950°~1000°
Nitrided Depth	0.50~0.7mm
Nitrided Brittleness	above 2 stage
Surface Roughness	Ra0.4
Screw straightness	0.015mm
Hardess of surface chromium-plating afterNitriding	HV≥950HV
Chromium-plating Depth	0.05~0.10mm
ALLoy Depth	0.8~2.0mm
Alloy hardness	HRC56°~65°
Alloy	iron,nickel,tungsten,molybdenum
Types of screw	Gradual type,mutant type,wave type,barriertype,double screen type,shunt type,separation type,exhaust type,pintype,mixed type,double-head type,three-head type,multi head type etc.

Raw Material:	The finished product processing requirements:
38CrMoAlA,SACM645,42CrMo	nitriding treatment
42CrMo,AISI 4140	hard chrome coated layer
4Cr5MoSiV1,SKD-61,SKD-11	Sparying bimetal alloy layer and nitridingtreatment
HPM38,SI36,SUS440,9Cr18MoV	High frequency quenching
GHII3	Airset in high temperature
